LIFEBREATH 700 Pool Heat Recovery Ventilator

Special Order Item: This product ships directly from Lifebreath (the manufacturer). Please allow 6–8 weeks for delivery. All special order items are final sale and cannot be returned or exchanged.



• Designed For Indoor Pool Applications
• Contains 2 AHRI 1060 Certified 68-222 HEX Cores
• Field switch side access panel allowing either side maintenance access
• Upgraded for pool applications, lowest cost compared to other dehumidification installations
• Microprocessor circuit board with built in interlock contacts
• Field reversible
• SKU#700POOL



Specifications:

• CORES - Modular (2 section) patented aluminum
  heat recovery cores arranged for
  efficient counter-flow ventilation.
• MOTORS - Two PSC, 3 speed single shafted
  motors. 120 VAC, 4.5 Amps each (9
  Amps total on high speed). 1/4 HP,
  1450 RPM. 1032 Watts on high speed.
  MCA: 22.5 MOP: 15.
• BLOWERS - Slide easily in / out of unit. Centrifugal
  type rated at 700 cfm (329 L/s) free air
  delivery.
• MERV 6 FILTERS - Washable air filters in exhaust and
  supply air streams. MERV 13 Upgrade: 65-195-6R.
• MOUNTING - Unit to be set on support brackets hung
  by threaded rod type apparatus
  (brackets and rod not provided), or
  placed on vibrations isolation pads.
• DEFROST - Supply bypass routes indoor air to
  defrost core.
• CASE - Unit has front and back access doors.
  Electrical panel can be switched to
  either front or back, giving installer
  flexibility in duct direction. 22 gauge
  prepainted galvanized steel (G60)
  for superior corrosion resistance.
  Insulated with elastomeric insulation.
  Drain connections: two - 1/2” (12mm)
  O.D.
• ELECTRONICS -  Integrated microprocessor circuit
  board. Built-in interlock contacts.
• WARRANTY - Units carry a 15 year warranty on HRV
  core and 2 year replacement parts
  warranty.
